Views: 3 Author: Site Editor Publish Time: 2018-12-08 Origin: Site
PLC reinforcing fencing wire mesh welding machine, is also called plc control heavy duty rebar mesh welding machine. The cross wires are fallen from hopper automatically, driven by step motor. The line wires are threaded manually and fed automatically. The finished mesh is pulled by step motor, which ensures accuracy and improves productivity. The transformers and welding electrodes are both equipped with cold water cooling system, which reduces heat immediately and prolongs their service life. All these characteristics make reinforced rebar mesh welded machine an excellent equipment.
Model | HWSB-2500 | HWSB-3000 | HWSB-2500A |
Wire diameter | 3-8mm | 3-8mm | 5-12mm |
Welding width | ≤2500mm | ≤3000mm | ≤2500mm |
Longitude wire space | 100-300mm | 100-300mm | 100-300mm |
Cross wire space | Min.50mm | Min.50mm | Min.50mm |
Mesh length | Max.12000mm | Max.12000mm | Max.12000mm |
Wire feeding way | Pre-straightened, cut to length | ||
Welding speed | 50-75times/min | 50-75 times/min | 40-65times |
Welding electrodes | 24 | 31 | 24 |
Welding transformers | 150kva*6 | 150kva*8 | 150kva*12 |
Machine size | 8.4*3.4*1.6m | 8.4*3.9*1.6m | 8.4*5.5*2.1m |
Weight | 5.2T | 6.2T | 8.5T |
Our Service:
1. If the customer need, we can send our technical staff to the buyers’ factory to install the machine and providing the training in 15 days after the machines arrived the destination port.
2. Maintenance period: one year for whole machine except vulnerable parts.
3. Engineers overseas service is available. The number of technical persons: one technician per machine.
Much more details, feel free to contact.
